New Electric Compactors Help You Earn More
Description
We are expanding our portfolio of electric machines to the road segment with the Volvo DD25 Electric asphalt compactor. It is a zero-exhaust emission solution for small scale compaction projects including street repairs and patching, parking lots, driveways, municipalities and rental houses.
With the introduction of this electric compact double-drum roller, we continue to lead the way with innovations that help customers reduce their total cost of ownership and carbon footprint – while maintaining high productivity and uptime.
Features And Benefits
- Ideal for sensitive or urban environments with strict emission regulations and for organizations which are looking to meet their own sustainability goals.
- Cleaner and more enjoyable work environment for operators, site teams and passers-by.Opportunity for a completely zero-emission workplace if used alongside other Volvo electric powered equipment – such as the EC18 Electric, ECR18 Electric and the ECR25 Electric compact excavators, or the L25 Electric and L20 Electric compact wheel loaders.
Images
Brochures
Video
DRIVELINE
Transmission Hydrostatic
Power 32.9 hp (24.5 kW)
Capacity 20 kW-h
DIMENSIONS
Overall Length 95.3 inches (2420 mm)
Height - With ROPS 104.3 inches (2650 mm)
Height - Without ROPS 79.5 inches (2020 mm)
Overall Width 42.9 inches (1090 mm)
Wheelbase 67.7 inches (1720 mm)
Drum Width - Front 39 inches (1000 mm)
Drum Width - Rear 39 inches (1000 mm)
Rolling Width 39 inches (1000 mm)
Drum Diameter - Front 28 inches (700 mm)
Drum Diameter - Rear 28 inches (700 mm)
Drum Shell Thickness 0.51 inches (13 mm)
Capacities
Fuel Tank 10.6 gallons (US) (40 ltr)
DEF Tank 7.1 gallons (US) (27 ltr)
Tank Capacity For Drum 68.7 gallons (US) (260 ltr)
Performance
Drive To Drums Both
Travel Speed 1 6.4 mph (10.3 kph)
Max. Travel Speed 6.4 mph (10.3 kph)
Number Of Frequency/Amplitude Settings 2
Frequency - Stage 1 - Front 55 Hz
Frequency - Stage 2 - Front 67 Hz
Frequency - Stage 1 - Rear 55 Hz
Frequency - Stage 2 - Rear 67 Hz
Amplitude Stage 1 - Front 0.021 inches (0.53 mm)
Amplitude Stage 1 - Rear 0.021 inches (0.53 mm)
Centrifugal Force 1 - Front 8430 lbf (38 kN)
Centrifugal Force 2 - Front 5732 lbf (26 kN)
Centrifugal Force 1 - Rear 8430 lbf (38 kN)
Centrifugal Force 2 - Rear 5732 lbf (26 kN)
Max Amplitude 0.021 inches (0.53 mm)
Max Frequency 67 Hz
Min Frequency 55 Hz
Max Centrifugal Force 8430 lbf (38 kN)
Min Centrifugal Force 5732 lbf (26 kN)
Weights
Operating Weight 5899 lbs (2676 kg)
Weight - Front 2985 lbs (1353 kg)
Weight - Rear 2915 lbs (1323 kg)
