Description
Standard Arm Length 5 ft 3 in (1600 mm)
Telematics
Telematics Available Option
Driveline
Engine Manufacturer Volvo
Engine Model D 2.6H
Displacement 160 Inches³ (2.61 ltr)
Rated Speed 2200 rpm
Engine Output - Net 57 hp (42.7 kW)
Engine Output - Gross 59.4 hp (44.3 kW)
Number Of Track Rollers - Each Side 5
Track Shoe Width 16 inches (400 mm)
Dimensions
Bucket Weight 280 lbs (129 kg)
Transport Length Mono Boom 19 ft (5800 mm)
Max Transport Height 8 ft 6 in (2584 mm)
Max Machine Width 6 ft 8 in (2020 mm)
Track Length On Ground 6 ft 6 in (1990 mm)
Zero Tailswing No
Track Gauge - Standard 5 ft (1520 mm)
Variable Undercarriage Availability No
Ground Level Reach 19 ft 7 in (5970 mm)
Dig Height 18 ft 8 in (5695 mm)
Dump Height - Mono Boom 13 ft 7 in (4150 mm)
Dig Depth 12 ft 1 in (3695 mm)
Mono Boom - Size 9 ft 10 in (3 m)
Standard Arm 5 ft 3 in (1600 mm)
Longest Arm 6 ft 3 in (1900 mm)
Capacities
Fuel Tank 29 gallons (US) (105 ltr)
Performance
Ground Bearing Pressure 5 PSI (32.3 kPa)
Standard Shoe Width 16 inches (400 mm)
Arm Tearout 6470 lbf (28.8 kN)
Bucket Breakout 9720 lbf (43.3 kN)
Main Pump Variable axial piston
Number Of Main Pumps 2
Main Pump - Flow 32 gallons (US) / min (121 lt/min)
Weights
Operating Weight 12830 lbs (5730 kg)
