Telematics
Telematics Available Yes
Driveline
Engine Manufacturer Volvo
Engine Model D4J
Displacement 246.5 Inches³ (4.04 ltr)
Rated Speed 2000 rpm
Engine Output - Net 137 hp (102 kW)
Engine Output - Gross 141 hp (105 kW)
Standard Number Of Tires 8
Tire Size - Standard 10.00-20
Dimensions
Transport Height Over Boom 10 ft 11 in (3330 mm)
Overall Width 8 ft 4 in (2540 mm)
Overall Width Stabilizers Down 13 ft 1 in (3990 mm)
Wheelbase 8 ft 6 in (2600 mm)
Ground Level Reach 26 ft 11 in (8200 mm)
Maximum Dig Height - Mono Boom 28 ft 1 in (8560 mm)
Dump Clearance Height - Mono Boom 18 ft 10 in (5740 mm)
Dig Depth - Mono Boom 16 ft 8 in (5070 mm)
Capacities
Fuel Tank 52.8 gallons (US) (200 ltr)
Reference Capacity 0.95 yd³ (0.73 m³)
Performance
Swing Speed 9 rpm
Bucket Breakout - Mono Boom 24392 lbf (108.5 kN)
Dipper Tearout - Boost, Mono Boom 14275 lbf (63.5 kN)
Total Flow - Main Pumps 73 gallons (US) / min (275 lt/min)
Weights
Operating Weight 36376 lbs (16500 kg)
