ECR58
914d935a-e8db-4fb4-888c-590f7e550ebf
Description
Features And Benefits
Images
Brochures
Video
Description
Standard Arm Length 5 ft 5 in (1650 mm)
Telematics
Telematics Available Yes
Driveline
Engine Manufacturer Volvo
Engine Model D 2.6H
Displacement 160 Inches³ (2.615 ltr)
Rated Speed 2200 rpm
Engine Output - Gross 48 hp (35.5 kW)
Number Of Track Rollers - Each Side 5
Track Shoe Width 15.7 inches (400 mm)
Dimensions
Bucket Capacity 0.188 yd³ (0.144 m³)
Bucket Weight 249 lbs (113 kg)
Transport Length Mono Boom 20 ft (6105 mm)
Max Transport Height 8 ft 4 in (2540 mm)
Max Machine Width 6 ft 7 in (2000 mm)
Track Length On Ground 6 ft 7 in (2000 mm)
Zero Tailswing No
Heaped Bucket Capacity 0.188 yd³ (0.144 m³)
Bucket Width - Standard 23.6 inches (600 mm)
Track Gauge - Standard 5 ft 3 in (1600 mm)
Ground Level Reach 19 ft 7 in (5972 mm)
Dig Height 18 ft 3 in (5565 mm)
Dump Height - Mono Boom 13 ft 1 in (3996 mm)
Dig Depth 13 ft (3957 mm)
Standard Arm 5 ft 5 in (1650 mm)
Longest Arm 6 ft 7 in (1950 mm)
Capacities
Fuel Tank 18.5 gallons (US) (70 ltr)
Performance
Ground Bearing Pressure 4.75 PSI (32.8 kPa)
Standard Shoe Width 15.7 inches (400 mm)
Arm Tearout 6387 lbf (28.41 kN)
Bucket Breakout 9422 lbf (41.91 kN)
Main Pump Piston
Number Of Main Pumps 1
Main Pump - Flow 37.8 gallons (US) / min (143 lt/min)
Weights
Operating Weight 12875 lbs (5840 kg)
