Construction Division
EC230
b526972a-f755-4c2d-9828-7e84f6836bbd
Description
With its cutting-edge technology, outstanding efficiency and robust design,
the EC230 effortlessly handles heavy loads, tackles tough terrain, and ensures exceptional productivity across a wide range of tasks and applications. Whether you’re working in general construction, road building or something more specialist, the Volvo EC230 is a versatile and high performing machine designed to help you achieve outstanding results.
Features And Benefits
- Personalised settings for greater comfort
- Ground level access for service
- Radar warns for items outside the screen
Images
Brochures
Video
Description
Standard Arm Length 9 ft 6 in (2900 mm)
Telematics
Telematics Available Yes
Driveline
Engine Manufacturer Volvo
Engine Model D6J
Displacement 348 Inches³ (5.8 ltr)
Rated Speed 1800 rpm
Engine Output - Net 172 hp (128 kW)
Engine Output - Gross 173 hp (129 kW)
Number Of Track Rollers - Each Side 8
Track Shoe Width 32 inches (800 mm)
Dimensions
Bucket Capacity 0.63-1.73 yd³ (0.48-1.32 m³)
Bucket Weight 1468-2295 lbs (666-1041 kg)
Transport Length Mono Boom 31 ft 10 in (9715 mm)
Max Transport Height 9 ft 11 in (3035 mm)
Max Machine Width 9 ft 10 in (2990 mm)
Track Length On Ground 12 ft (3660 mm)
Zero Tailswing No
Variable Undercarriage Availability No
Ground Level Reach 32 ft 3 in (9835 mm)
Dig Height 31 ft (9445 mm)
Dump Height - Mono Boom 21 ft 6 in (6555 mm)
Dig Depth 22 ft 5 in (6825 mm)
Capacities
Fuel Tank 83 gallons (US) (315 ltr)
Performance
Ground Bearing Pressure 5.4 PSI (37.3 kPa)
Arm Tearout 24730 lbf (110 kN)
Bucket Breakout 33500 lbf (149 kN)
Number Of Main Pumps 2
Main Pump - Flow 110 gallons (US) / min (416 lt/min)
Weights
Operating Weight 53030 lbs (24050 kg)
