CR30B
d17f41a9-6627-488b-9fe6-7d1f080bc6c4
MAINTAIN YOUR PRODUCTIVITY
Description
The DD30B asphalt roller from Volvo, a highly efficient machine designed to increase performance and reduce fuel consumption on small scale compaction projects. Featuring the new engine, this machine meets the Tier 4 Final emissions regulations. Experience high performance machine and enhanced productivity with Volvo.
Features And Benefits
- High Productivity
- Lifetime Frame & Structure Guarantee (Frame, Articulation Joint)
Images
Brochures
Video
Driveline
Engine Manufacturer Kubota
Engine Model D 1803 - CR-TE4B
Diesel Oxidation Catalyst Yes
Selective Catalytic Reduction No
Displacement 111.43 Inches³ (1.826 ltr)
Rated Speed 2700 rpm
Engine Rated Power 49.6 hp (37 kW)
Steering Type Articulated
Tire Size 7.5 - 15
Number Of Tires 4
Dimensions
Overall Length 102.9 inches (2614 mm)
Height Over ROPS 107.3 inches (2725 mm)
Overall Width 51.3 inches (1303 mm)
Wheelbase 68.6 inches (1742 mm)
Ground Clearance 7.3 inches (185 mm)
Drum Width - Front 47.2 inches (1200 mm)
Width Over Tyres 3 ft 9.3 in (1150 mm)
Rolling Width 47.2 inches (1200 mm)
Drum Shell Thickness 0.5 inches (12 mm)
Turn Radius - Inside 104.3 inches (2648 mm)
Capacities
Fuel Tank 17.4 gallons (US) (66 ltr)
Performance
Travel Speed 1 7.3 mph (11.8 kph)
Frequency - Stage 1 - Front 69 Hz
Amplitude Stage 1 - Front 0.02 inches (0.43 mm)
Centrifugal Force 1 - Front 7615 lbf (33.9 kN)
Weights
Operating Weight 6005 lbs (2724 kg)
Weight On Front 3125 lbs (1417 kg)
Weight On Rear 2880 lbs (1306 kg)
