Construction Division
EW200E MH
f77082e4-8ea6-488d-8779-a66ca0a8f67e
Description
EXCAVATOR EXCELLENCE
Get ready to work with the EW220E, offering precise movements to help you maintain total control. Fitted with a powerful Volvo engine and perfectly matched hydraulic system to deliver high performance, excellent control and low fuel consumption, the versatile machine makes easy work of even the most demanding applications.
Features And Benefits
- ENHANCED CONTROLLABILITY
- Experience ultimate control of the entire machine from the intuitive joysticks, including tiltrotator, blade and outriggers.
- REACH FURTHER, LIFT MORE
- The heavy-duty two-piece boom and arm offers a total reach of over 10 meters, giving you the versatility to do even more.
- STEELWRIST® TILTROTATOR
- Boost productivity and reduce fuel consumption with the factory-fitted Steelwrist® tiltrotator, offering ultimate control using the two joysticks and machine display.
- SUPERIOR SERVICEABILITY
- Greasing points are grouped together for fast maintenance and filters placed behing wide-opening engine doors.
Images
Brochures
Video
Description
Longest Dipper 13 ft 1 in (4000 mm)
Reference Dipper 11 ft 5 in (3500 mm)
Driveline
Engine Manufacturer Volvo
Engine Model D6J
Displacement 348 Inches³ (5.7 ltr)
Engine Output - Net 169 hp (126 kW)
Engine Output - Gross 173 hp (129 kW)
Number Of Motor Speeds Infinitely variable
Standard Number Of Tires 8
Service Brake Location Axle
Dimensions
Overall Width 8 ft 3 in (2520 mm)
Tailswing Radius 7 ft 2 in (2190 mm)
Cab Riser Hydraulic
Overall Width Stabilizers Down 13 ft 3 in (4040 mm)
Max Reach - Straight Boom - Standard 39 ft 1 in (11900 mm)
Max Height - Straight Boom - Attachment Pivot 36 ft 9 in (11200 mm)
Max Depth - Straight Boom - Attachment Pivot 4 ft 11 in (1500 mm)
Oscillation Front Axle
Capacities
Fuel Tank Capacity 66 gallons (US) (250 ltr)
Performance
Main Pumps Maximum Flow 79.3 gallons (US) / min (300 lt/min)
Weights
Operating Weight 50376 lbs (22850 kg)
Standard Attachment Type Sorting grab
