Description
Standard Arm Length 9 ft 10 in (3000 mm)
Telematics
Telematics Available Yes
Driveline
Engine Manufacturer Volvo
Engine Model D4J
Displacement 247 Inches³ (4.04 ltr)
Rated Speed 2000 rpm
Engine Output - Net 119 hp (89 kW)
Engine Output - Gross 121 hp (90 kW)
Number Of Track Rollers - Each Side 7
Track Shoe Width 24 inches (600 mm)
Dimensions
Bucket Capacity 0.33-1.01 yd³ (0.25-0.77 m³)
Bucket Weight 729-1193 lbs (330-541 kg)
Transport Length Mono Boom 25 ft 1 in (7640 mm)
Max Transport Height 10 ft 6 in (3310 mm)
Max Machine Width 9 ft (2740 mm)
Track Length On Ground 10 ft (3040 mm)
Zero Tailswing No
Heaped Bucket Capacity 0.71 yd³ (0.54 m³)
Variable Undercarriage Availability No
Ground Level Reach 28 ft 7 in (8720 mm)
Dig Height 28 ft 7 in (8710 mm)
Dump Height - Mono Boom 20 ft 8 in (6290 mm)
Dig Depth 19 ft 11 in (6090 mm)
Capacities
Fuel Tank 66 gallons (US) (250 ltr)
Performance
Ground Bearing Pressure 5.1 PSI (35.3 kPa)
Arm Tearout 13430 lbf (59.7 kN)
Bucket Breakout 21720 lbf (96.6 kN)
Number Of Main Pumps 2
Main Pump - Flow 66 gallons (US) / min (248 lt/min)
Weights
Operating Weight 31790 lbs (14390 kg)
